1999-2024 Superduty 6" Lift Kit with FOX 2.0 Performance Shocks (BDS311FS)

BDS 6" lift kit for the 1999-2004 Ford F250 and F350 Super Duty 4WD, with clearance for up to 36" tires. Up front it runs BDS Glide-Ride triple-stage progressive leaf springs for full lift and load capacity, a forged drop pitman arm and track bar relocation bracket to correct steering geometry, sway bar links, bump stop brackets and FOX 2.0 Performance Series shocks. The rear uses a high-strength lift block, longer u-bolts and matching FOX 2.0 Performance Series shocks.

Features

• 100% bolt-on installation
• Glide-Ride triple-stage progressive leaf springs provide full lift height and increased capacity
• Track bar relocation bracket and forged drop pitman arm maintain proper steering angles
• Cast steel rear blocks for a level front-to-rear stance, designed for correct pinion angles
• FOX 2.0 Performance Series shocks: 2" Impact extruded aluminum body, IFP monotube design
• CNC machined 6061-T6 aluminum mounting ends
• 5/8" hard chrome plated heat-treated alloy steel shaft
• Race-developed high-flow piston with application-specific valving
• Long-lasting clear anodized finish

Specs

• Front Lift Method : Leaf Spring
• Rear Lift Method : Block & Add-A-Leaf
• Shocks Included : Yes
• Front Lift Height : 6 inch
• Rear Lift Height : 5 inch

Notes

• (Trimming may be required)
• These truck were manufactured with two different style front u-bolts.
• You will need to know if your front leaf spring u-bolts are square or are half way between round and square with a gentle radius around the OE cast u-bolt plate before ordering.
• Vehicles produced before 3/1/99 require a different box kit.
• You must check the production date on the door prior to ordering.
• The Superduty came from the factory with a 2", 3", or 4" rear block. If you wish to truly level your vehicle it may be necessary to change the rear OE block.
• Will not fit dually applications.
• If your vehicle is equipped with a carrier bearing, you will want the 123402 drop kit in the options section.
• The front driveshaft will need to be lengthened and/or clearance ground depending on how the vehicle is equipped.

Includes

• BDS003602, Ford F250/350 6 Inch Front Spring (UPC 658848611362)
• BDS003609, Ford F250/350 6 Inch Rear Spring (UPC 658848611386)
• BDS013004, Pre 2/99 Ford F250/350 6&8in Front Bx Kt (UPC 658848612949)
• BDS013009, Ford F250/350 6&8in Rear Box Kit (UPC 658848612987)
• FOX98224660, Fox 2.0 Shock 30.05 x 18.45 x 2- EB1/EB1
• FOX98224760, Fox 2.0 Shock 33.85 x 20.75 x 2- EB1/EB1
