2000-2002 Ram HD 5" Lift Kit with FOX 2.0 Performance Shocks (BDS221FS)

This BDS 5" lift kit raises your 2000-2002 Dodge Ram 2500/3500 4WD with clearance for up to 35" tires. Up front it runs diesel-specific progressive-rate Pro-Ride coil springs, all four control arms plus a relocation bracket, a forged drop pitman arm and track bar drop bracket for steering correction, bump stops, and sway bar drop brackets. BDS engineered longer-than-stock lower control arms to rotate the axle for proper alignment and a relocation bracket to flatten the upper arm angle and keep factory handling. The rear uses a heavy duty cast steel block and add-a-leaf combo with longer u-bolts. Choose NX2 Nitro or FOX 2.0 Performance shocks front and rear.

Features

• Tubular short arms improve strength, handling and caster control
• Heavy duty control arm brackets maintain proper suspension geometry
• Front high strength progressive rate coil springs
• Front track bar relocation bracket to re-position axle
• Forged drop pitman arm to correct steering angles
• Front sway bar correction to maintain handling performance
• Choice of BDS NX2 Nitro gas or FOX 2.0 Performance Internal Floating Piston shocks
• Rear add-a-leaf eliminates any need for a lift block, reduces axle wrap, and maintains factory payload ratings
• FOX 2.0: 2-inch Impact extruded aluminum body, Internal Floating Piston monotube design, CNC machined 6061-T6 aluminum mounting ends, 5/8-inch hard chrome plated heat-treated alloy steel shaft, race-developed high-flow piston, application-specific valving, clear anodized finish

Specs

• Front Lift Method: Coil Spring
• Rear Lift Method: Block
• Shocks Included: Yes
• Front Lift Height: 5 inch
• Rear Lift Height: 4.5 inch

Notes

• May require exhaust modification.
• Dual stabilizer may be substituted for the single stabilizer that comes in the kit.
• These vehicles were produced with and without a top mounted overload spring. You will need to identify which your vehicle has before ordering the rear block & add-a-leaf kit.

Includes

• BDS002458, Dodge Ram 3/4 ton 4.5in Rear Spring (UPC 658848611270)
• BDS012504, 00-01 Dodge 1500/2500 5in Front Box Kit (UPC 658848612529)
• BDS012508, 94-02 Dodge 2500 Rear Bx Kit w/BDS Rear (UPC 658848612543)
• BDS032503, 94-up Dodge Ram 2500(Diesel) Coil Kit (UPC 658848616398)
• BDS85406, Steering Stab 23.9 x 14.3 - EB1/EB1 (UPC 711745609051)
• FOX98224750, Fox 2.0 Shock 28.25 x 17.15 x 2- S50/EB1
• FOX98224761, Fox 2.0 Shock 33.85 x 20.75 x 2- EB1/EB1
