2005-2007 Superduty 6" Lift Kit with FOX 2.0 Performance Shocks (BDS350FS)

BDS 6" lift for the 2005-2007 Ford F250 and F350 Super Duty diesel truck with clearance for up to 37" tires. Up front it includes diesel-specific Pro-Ride coil springs, heavy duty radius arm drop brackets, a forged drop pitman arm and track bar bracket for steering correction, sway bar relocation, brake line brackets, and custom-tuned nitrogen charged shocks. In the rear the base kit uses high strength lift blocks, longer u-bolts, brake line brackets, and matching NX2 Nitro or FOX Performance shocks.

Features

• Easy, 100 percent bolt-on installation
• Pro-Ride dual rate coil springs provide a remarkable ride through any terrain
• Heavy duty radius arm drop brackets provide correct caster and maintain your stock driving characteristics
• Track bar relocation bracket and pitman arm maintain proper steering angles for improved handling
• Cast iron lift blocks with built-in bump stop provide level stance and correct pinion angle with offset pin to restore axle position
• Standard NX2 Nitro shocks with vehicle-specific valving for better control
• Upgrade to FOX 2.0 Performance Series shocks for maximum performance on and off-road
• 2-inch impact extruded aluminum body
• Internal floating piston monotube design
• CNC machined 6061-T6 aluminum mounting ends
• Massive 5/8-inch hard chrome plated heat-treated alloy steel shaft
• Race-developed high-flow piston design
• Application-specific valving to maximize performance
• Long-lasting clear anodized finish

Specs

• Front Lift Method: Coil Spring
• Rear Lift Method: Block
• Shocks Included: Yes
• Front Lift Height: 6 inch
• Rear Lift Height: 5 inch

Recommended Tire & Wheel Fitment

• Tire Size: 37x12.5
• Wheel Diameter: 18x9, 20x9
• Back Spacing: 4.5/4.5

Notes

• These trucks were manufactured with and without top mounted overload springs on the rear leaf springs (an extra leaf set above the main leaf). You will need to identify which you have before ordering.
• If your vehicle is equipped with a carrier bearing, you will need to order 123402 in the options section.
• Do not install the 4 inch rear block kit on vehicles equipped with a factory 3-7/8 inch rear block; use only the rear spring option on these vehicles.

Includes

• BDS013418, 2005-2007 Ford F250/F350 4 Inch Rear Box w/ Overload (UPC 658848613465)
• BDS013611, 05 Ford F250/350 6 Inch Front Box Kit (UPC 658848613793)
• BDS033611, 2005-2022 Ford F250/F350 6 inch (Diesel) Coil Kit (UPC 658848616589)
• BDS85415, Steering Stab 23.9 x 14.3 - EB1/EB1 (UPC 711745609112)
• FOX98224750, Fox 2.0 Shock 28.25 x 17.15 x 2- S50/EB1
• FOX98224760, Fox 2.0 Shock 33.85 x 20.75 x 2- EB1/EB1
