2005-2023 Tacoma 2.5" SST2.1 Suspension System w/ Falcon 2.1 Front Strut Shocks (62-55310)

The ReadyLIFT 2.5-inch SST2.1 Suspension System for Toyota Tacoma is a complete suspension upgrade that eliminates the factory nose-down rake while significantly enhancing ride quality. By combining Falcon 2.1 performance shocks with CNC-machined billet aluminum strut spacers, this kit provides 2.5 inches of front lift and 1.5 inches of rear lift. This system allows for the fitment of larger off-road tires and provides increased ground clearance, making it an ideal choice for Tacoma owners who want a versatile rig for both daily driving and weekend adventures.

Features

• Falcon 2.1 Monotube performance shocks provide a significant upgrade in damping and roll control.
• Front strut extensions provide 2.5 inches of lift using CNC-machined billet aluminum spacers for superior durability.
• Rear lift is achieved via 1.5-inch blocks or spacers to create a perfectly leveled, aggressive stance.
• Differential drop spacers are included for 4WD models to maintain proper CV axle angles.
• Maintains factory-standard suspension travel and steering geometry for a smooth, reliable ride.
• Retains the factory turning radius and overall safety characteristics of the vehicle.
• Simple bolt-on installation requires no permanent modifications to the vehicle frame.

Notes

• Vehicle alignment is mandatory after installation to ensure proper tire wear and handling.
• Estimated installation time is approximately 3 to 4 hours excluding alignment.
• The 2.5 inches of lift is calculated from a stock Tacoma; TRD Pro models will gain less height.

Compatibility Notes

• Compatible with TRD, SR5, and Rock Warrior trim levels.
• Not compatible with 5-lug Tacoma models.
• Does not fit 2024 or newer (4th Generation) Tacoma models.

Tire Fitment

• Maximum Tire Diameter: 31.5 inches (285/70R17 or 285/75R16).
• Recommended Setup: 285/70R17 tires on a 9-inch wide wheel with a 0 to +12 offset.
• Minor trimming of the front plastic inner fender liner may be required for full clearance with 285-series tires.

Shock Features

• Shock Type: Falcon 2.1 Monotube performance dampers.
• Construction: 2.125-inch 6061-T6 aluminum alloy shock bodies for high impact resistance and heat dissipation.
• Technology: Features Volume Optimized Damping (VOD) with a digressive linear piston for improved control at all speeds.
• Fluid: Uses Red Line high VI shock oil for consistent performance in extreme temperature ranges.

Specs

• Front Lift Height: 2.5 inches.
• Rear Lift Height: 1.5 inches.
• Kit Contents: Front Strut Spacers, Falcon 2.1 Shocks (Rear), Differential Drop Spacers (for 4WD), and Rear Lift Blocks/Hardware.
