2007-2015 Tundra 7" Lift Fox 2.5 PES Coilovers (BDS813FPE)

Engineered for serious Tundra enthusiasts, this 7" lift system pairs Fox Performance Elite coil overs with precision-tuned BDS components including reinforced upper control arms and steering knuckles. The result is a suspension setup that delivers responsive handling on technical terrain while maintaining composure during daily driving. Enhanced ground clearance opens new trail possibilities, while the quality damping characteristics of Fox shocks ensure consistent performance across varied conditions. Built for trucks that demand both capability and reliability.

Features

• FOX 2.5 Performance Elite series adjustable coil overs for improved ride quality, performance, and capability.
• High clearance crossmember design maximizes ground clearance Robust steering knuckles maintain ESC system compliance.
• HD skid plate system improved offroad protection.
• Multipoint differential relocation brackets to secure the front axle and improve CV angles.
• FOX performance series IFP gas rear shocks to improved ride and offroad performance.
• Factory Protection Plus drivetrain warranty included


Shock Features

• Increased off-road capabilities
• Easily adjust your shock for terrain, load and speed
• 2.5-inch Impact extruded aluminum body
• Massive 7/8-inch hard chrome plated heat-treated alloy steel shaft
• External reservoir design separates shock oil from the high-pressure nitrogen
• DSC - Dual Speed Compression Adjuster comes standard
• Fully serviceable for a lifetime of use
• 1-year Manufacturer's Warranty

Notes

• Requires from bracket modification and welding.
• No strut disassembly required.
• Stock 18" wheels can not be installed. factory 20" wheels with more than 6.25" backspacing can not be installed.
• Models with two piece rear drive line would require rear drive shaft modification.
• Models equipped with 6 piston calipers will require clearance machining on the caliper near the bolt holes on the mounting surface.
• Will NOT work on TRD Pro (Bilstein and Fox Piggyback Strut) models.

Specifications

• Front Lift Method : Coil-Over
• Front Lift Height : 7"
• Rear Lift Method : Block
• Rear Lift Height : 4"
• Shocks Included : Yes
• Lift Height : 6-7.5"

Tire Fitment

• 35 x 12.5 with 17 x 9 and 5.5 in. Backspace
• 37 x 12.5 with 18 x 9 and 6.25 in. Backspace
• 37 x 12.5 with 20 x 9 and 6.25 in. Backspace
