2013-2019 Ram HD 4.5" Front 2.0 Rear SST Lift Kit w/ Track Bar Bracket (69-1342)

The ReadyLIFT 4.5-inch Front / 2-inch Rear SST Lift Kit for 2013-2018 Dodge Ram 3500 4WD trucks is an engineered solution designed to provide significant lift without compromising the vehicle's factory ride or handling. This kit utilizes durable black e-coated steel coil spacers that allow owners to retain their factory front coil springs while achieving enough clearance for up to 37-inch tires. Complete with radius arm drop brackets and a front track bar bracket, this system maintains proper suspension geometry for a reliable and controlled driving experience.

Features

• Provides 4.5 inches of front lift and 2.0 inches of rear lift for a leveled, aggressive stance.
• Durable black e-coated steel coil spacers ensure ride height is maintained without deterioration over time.
• Includes radius arm drop brackets to preserve factory caster and suspension geometry.
• Front track bar bracket ensures the axle remains properly centered under the frame.
• Front shock extensions allow for the retention of factory-length shocks.
• Extended front bump stops protect the suspension components during articulation.
• OEM-style rear lift blocks provide a slight rake, ideal for towing and hauling applications.
• Clears up to 37-inch tires for improved off-road capability and aesthetics.

Notes

• A professional wheel alignment is required after installation to ensure optimal handling and safety.
• Headlamp aim must be checked and adjusted for safety following the significant change in ride height.
• Advanced Driver Assistance Systems (ADAS) should be recalibrated to maintain proper monitoring and function.
• Gas engine trucks may sit slightly nose-high as the kit is optimized for heavier Diesel engines.
• Installation by a certified mechanic is recommended to ensure all critical suspension geometry corrections are performed correctly.

Compatibility Notes

• Fits 2013–2018 Dodge Ram 3500 4WD models with the radius arm suspension and rear leaf springs.
• Not compatible with "New Body" style Rams, Power Wagon models, or vehicles equipped with Auto-Ride.
• Designed primarily for Single Rear Wheel (SRW) applications; Dual Rear Wheel (DRW) models may require custom U-bolts.
• Single Cab configuration has not been validated for fitment and drivability by ReadyLIFT.

Specs

• Front Lift Height: 4.5 inches.
• Rear Lift Height: 2.0 inches.
• Maximum Tire Diameter: 37 inches.
• Material: E-Coated Steel (Spacers) and OEM-Style Cast Iron (Blocks).
• Kit Contents: Two front coil spacers, two radius arm drop brackets, two front shock extensions, two extended bump stops, one front track bar bracket, two rear lift blocks, and all necessary hardware.
