2014-2018 Ram HD 3" Lift Kit with FOX 2.0 Performance Shocks (BDS1712FS)

BDS 3" radius arm lift kit for the 2014-2018 Ram 2500 diesel with factory rear air ride, clearing up to 35" tires. The front uses diesel-specific progressive-rate Pro-Ride coil springs, high-strength tubular replacement radius arms, a 1-3/8" solid steel adjustable track bar that recenters the front axle and bolts to the factory mounts, sway bar links, and brake line brackets. The rear runs heavy duty air bag spacer brackets, a track bar relocation bracket, bump stop extensions, and new air ride leveling sensor brackets that reposition the ride height sensors to keep the system working as it does at stock height.

Features

• Heavy duty tubular radius arms improve strength, handling and caster control
• Front high strength progressive rate coil springs
• Front adjustable 1-3/8" solid steel track bar re-centers the axle
• Forged drop pitman arm corrects steering angles
• Front sway bar correction maintains handling performance
• Air ride leveling sensor brackets maintain factory air ride function and bag range of motion
• FOX 2.0 Performance Series IFP monotube shocks
• 2" Impact extruded aluminum body with CNC machined 6061-T6 aluminum mounting ends
• 5/8" hard chrome plated heat-treated alloy steel shaft
• Race-developed high-flow piston design with application-specific valving
• Long-lasting clear anodized finish

Specs

• Front Lift Method: Coil Spring
• Rear Lift Method: Spacer
• Shocks Included: Yes
• Front Lift Height: 3 inch
• Rear Lift Height: 2 inch

Recommended Tire & Wheel Fitment

• Tire Size: 35x12.5
• Wheel Diameter: 18x9, 20x9
• Back Spacing: 5/5

Notes

• Designed for OE rear air-ride equipped models only.

Includes

• BDS012257, 2014-2024 Dodge Ram 2500 2.5 inch Rear Air Ride Box Kit (UPC 658848612154)
• BDS012312, 2014-2024 Ram 2500 / 2013-2024 Ram 3500 3 inch Front Box Kit (UPC 711745611436)
• BDS032302, 2013-2024 Ram 3500 / 2014-2024 2500 Ram Coils 3 inch Diesel - 4 inch Gas (UPC 658848616343)
• BDS122321, 2013-2024 Ram 2500 /2013-2024 Ram 3500 Radius Arm Box Kit (UPC 658848619429)
• FOX98224700, Fox 2.0 Shock 25.65 x 16.05 x 2- S50/EB1
• FOX98224706, Fox 2.0 Shock - 23.65 x 15.05 x 2- Special/EB1
