2014-2014 F-150 4" Lift Kit with FOX 2.0 Performance Shocks (BDS1504FS)

BDS 4" suspension lift kit for the 2014 Ford F150 2WD, with clearance for up to 35" tires. The high-clearance front end uses 1/4" steel crossmembers and a differential skid plate, CNC-machined ductile iron steering knuckles to correct steering geometry, plus sway bar relocation brackets, brake line brackets, and alignment cam bolts. The rear uses cast steel lift blocks and longer u-bolts with NX2 Nitro or optional FOX 2.0 Performance shocks.

Features

• High clearance crossmembers improve strength and offroad capability
• Heavy duty steering knuckles correct steering geometry and maintain ESC compatibility
• Top mounted strut spacers provide lift and install easily
• Differential skid plate for improved offroad protection
• Rear lift blocks and u-bolts level the stance
• Standard NX2 Nitro shocks with vehicle-specific valving
• Upgrade to FOX 2.0 Performance Series shocks for max on- and off-road performance

Specs

• Front Lift Method: Cross-Member
• Rear Lift Method: Block
• Shocks Included: Yes
• Front Lift Height: 4 inch
• Rear Lift Height: 4 inch

Recommended Tire & Wheel Fitment

• Tire Size: 37x12.5
• Wheel Diameter: 18x9, 20x9
• Back Spacing: 5/5.5

Notes

• 18" or larger diameter wheels required. Stock 17" and 18" wheels cannot be reinstalled. Stock 20" wheels can be used with up to a 305/60-20 tire.
• E-brake bracket required for factory powersteps (123018)
• Will not fit HD models (7 lug)
• For a level to tail-low appearance use #023416 with Kit #1504H. Block kits replace the factory 1-1/4" block.

Includes

• BDS023425, 2014 F150 4wd 4 Inch Strut Spacer Box Kit (UPC 658848615742)
• BDS023624, 09 Ford F150 2wd Front Box Kit (3of3) (UPC 658848615841)
• BDS023625, 2009-2014 Ford F150 4-6 Inch Box Kit (1of4) (UPC 658848615858)
• BDS023626, 2009-2014 Ford F150 4-6 Inch Box Kit (2of4) (UPC 658848615865)
• FOX98224828, Fox 2.0 Shock 31.02 x 18.95 x 2- EB1/EB1
