2015-2018 Sprinter 2500 4x4 Complete Striker 2" Lift Kit, Front and Rear (7035)

The Van Compass Striker 4x4 lift kit creates the clearance needed to fit larger tires and push deeper into back country with confidence. Carefully developed to lift the van with as few compromises as possible, it uses machined and welded spacers to keep the CVs, tie rods, and control arms cycling in their original Mercedes geometry. At the rear, a taller Mini Leaf Spring pack, longer sway bar links, shock relocation brackets, and bump stop spacers keep everything moving freely through full articulation.

Features

• Complete Van Compass Striker 2" 4x4 lift kit, front and rear
• Machined and welded front spacers retain original CV, tie rod, and control arm geometry
• Taller Mini Leaf Spring pack with longer sway bar links at the rear
• Includes shock relocation brackets and bump stop spacers for free articulation
• Fits up to a 35x12.50 tire with proper wheel offset and fender trimming
• Big increase in traction and ground clearance

Included Components

• Front 2" strut spacers
• Front 2" subframe drop spacers
• Engine and transmission mount 2" lift spacers
• CNC Machined 2" steering shaft extension
• Low pressure power steering hose extension
• Front brake line relocation brackets
• 6-leaf Mini Leaf Spring pack
• Extended rear sway bar links
• Rear lower shock relocation brackets
• Rear bump stop drop brackets
• Wind assist or headlight leveling sensor bracket
• All necessary hardware and detailed instructions

Important Notes

• Use Up To 35x12.5" Tires
• Raises Front 2"
• Raises Rear 2"
• Offset Wheels Recommended

Installation Instructions

• 2015-2018 NCV3 4x4 Striker 2" Front Kit Installation Instructions
• 2019-2022 VS30 4x4 Striker 2" Front Kit Installation Instructions
• 2015-2018 NCV3 4x4 Striker 2" Rear Kit Installation Instructions
• 2019+ VS30 4x4 Striker 2" Rear Kit Installation Instructions

Labor Time

Recommended shop labor time: 12 hours.

Specifications

• Grade Type: Regular
• Maximum Lift: 2.0 IN
• Maximum Lift Front: 2 IN
• Maximum Lift Rear: 2 IN
