2015-2018 Sprinter 2500 4x4 Suspension Lift Kit (7035-OPTI)

The Van Compass Striker lift kit creates the clearance you need to fit larger tires and push deeper into the backcountry with confidence. Years of careful development went into lifting the van with as few compromises to the factory design as possible: machined and welded spacers drop the front subframe so the CVs, tie rods, and control arms all cycle in their original geometry, while the rear pairs an Opti-Rate leaf pack with a 2" lift block, longer sway bar links, shock relocation brackets, and bump stop spacers.

Features

• Machined and welded spacers drop the front subframe to retain factory geometry
• CVs, tie rods, and control arms cycle in their original Mercedes-set range
• Opti-Rate rear leaf pack lets you fine-tune spring rate and ride height
• Includes a 2" rear lift block, longer sway bar links, shock relocation brackets, and bump stop spacers
• Best suited for heavy vans in the 9,000-10,000 lb range and up
• Allows fitment of a 35x12.50 tire with proper wheel offset and fender trimming

Included Components

• Front 2" strut spacers
• Front 2" subframe drop spacers
• Engine and transmission mount 2" lift spacers
• CNC Machined 2" steering shaft extension
• Low pressure power steering hose extension
• Front brake line relocation brackets
• Opti-Rate Rear leaf spring pack
• 2" rear lift block
• Extended rear sway bar links
• Rear lower shock relocation brackets
• Rear bump stop drop brackets
• Wind assist or headlight leveling sensor bracket
• All necessary hardware and detailed instructions

Important Notes

• Also requires part number 3037
• With this lift kit, tires up to 35" diameter and 12.5" width can fit. Trimming of the fender liner and mud flap is required.

Installation Instructions

• 2015-2018 NCV3 4x4 Striker 2" Front Kit Installation Instructions
• 2019-2022 VS30 4x4 Striker 2" Front Kit Installation Instructions
• Striker 2" Rear Kit with Opti-Rate Springs Installation Instructions

Labor Time

Recommended shop labor time: 12 hours.

Specifications

• Maximum Lift: 2.0 IN
