2015-2018 Sprinter 2500 4x4 Suspension Lift Kit (7035-UP)

This parts grouping is built specifically for customers with an existing Stage 4.3 kit who want to upgrade to a 6.3 kit, and it also takes a Stage 3 setup up to Stage 5 specifications. It pairs the front and rear lift components with three small leaves to upgrade your existing rear mini pack. Like the rest of the Striker line, it adds clearance for larger tires while keeping the stock ride and payload intact.

Features

• Upgrades an existing Stage 4.3 kit to 6.3, or Stage 3 to Stage 5 specs
• Pairs front and rear lift components with three small leaves for the rear mini pack
• Provides clearance for larger tires and added ground clearance
• Retains stock suspension geometry, payload rating, and ride quality
• Components constructed of high-quality materials in the USA
• Powder coated for durability and corrosion resistance

Included Components

• Front 2" strut spacers
• Front 2" subframe drop spacers
• Engine and transmission mount 2" lift spacers
• CNC Machined 2" steering shaft extension
• Low pressure power steering hose extension
• Front brake line relocation brackets
• 3 short leaves to convert 3-leaf Mini Leaf Spring pack to 6-leaf
• Extended rear sway bar links
• Rear lower shock relocation brackets
• Rear bump stop drop brackets
• Wind assist or headlight leveling sensor bracket
• All necessary hardware and detailed instructions

Important Notes

• Raises Front 2"
• Raises Rear 2"

Installation Instructions

• 2015-2018 NCV3 4x4 Striker 2" Front Kit Installation Instructions
• 2019-2022 VS30 4x4 Striker 2" Front Kit Installation Instructions
• 2015-2018 NCV3 4x4 Striker 2" Rear Kit Installation Instructions
• 2019+ VS30 4x4 Striker 2" Rear Kit Installation Instructions

Labor Time

Recommended shop labor time: 12 hours.

Specifications

• Maximum Lift: 2.0 IN
