2015-2018 Sprinter 3500 4x4 Suspension Lift Kit (7129-OPTI)

The Van Compass Striker 4x4 Sprinter 3500 2" lift kit creates clearance for larger tires and adds ground clearance under the van, helping you avoid obstacles on the trail to your remote campsite. It retains the stock suspension geometry while improving on factory ride quality and payload rating with a full replacement leaf spring pack matched to your vehicle's weight.

Features

• 2" of lift for larger tires and added ground clearance
• Full replacement rear leaf spring pack specified for your vehicle's weight
• Improves on factory ride quality and payload rating
• Retains stock suspension geometry
• Components built in the USA, powder coated for durability and corrosion resistance

Included Components

• Front 2.0" strut spacer - 1/4" hot rolled steel
• Front 2.0" subframe drop spacers - 4140 heat treated chromoly
• Motor mount 2.0" lift spacer - 3/16" hot rolled steel
• Transmission 2.0" lift spacer - 3/16" hot rolled steel
• 2" CNC Machined Steering shaft extension
• Low pressure power steering hose extension
• Front brake line relocation brackets
• Opti-Rate replacement rear¬¨‚Ćleaf spring pack
• Rear sway bar drop brackets - 3/16" hot rolled steel
• Rear lower shock mounts - 1/8" hot rolled steel
• Rear bump stop drop brackets - 1/8" hot rolled steel
• Rear wind assist extension bracket - 1/8" hot rolled steel
• All necessary hardware

Installation Instructions

• 2015-2018 NCV3 4x4 Striker 2" Front Kit Installation Instructions
• 2019+ VS30 4x4 Striker 2" Front Kit Installation Instructions
• 2007+ Sprinter 3500 4WD Rear Lift Kit Installation Instructions
• Sprinter 3500 4WD Rear Spring Installation Instructions

Labor Time

Recommended shop labor time: 12 hours.

Specifications

• Maximum Lift: 2.0 IN
