2017-2019 Superduty 2.5" Coil Spring Front Leveling Kit (46-2724)

The ReadyLIFT 2.5-inch Coil Spring Front Lift Kit is a performance and ride-enhancing leveling system designed for Super Duty trucks. It raises the front of the truck by 2.5 inches to achieve a leveled stance and includes premium front and rear Bilstein 5100 series shocks for a smooth, controlled ride both on and off-road. The kit includes specially engineered coil springs and a track bar relocation bracket to maintain proper suspension performance.

Features

• Includes specially engineered 2.5-inch lift front coil springs.
• Comes complete with four Bilstein 5100 series shocks (front and rear).
• Includes a front track bar relocation bracket.
• Features model-specific brake line extension brackets, bump stop extension brackets, and front sway bar frame mount extension brackets.
• Made in USA.

Notes

• Depending on the factory spring rate, the final lift height may vary from 1.5 inches to 2.5 inches.
• Not recommended for TREMOR editions.

Compatibility Notes

• For use on Diesel Trucks Only.
• Designed to fit Ford Super Duty F250, F350, and F450 4WD trucks.

Tire Fitment

• Allows for up to 35-inch tall tires.
• Recommended tire size is 35x12.50.
• 37-inch tires are possible but may require trimming.

Specs

• Front Lift: 2.5 inches (maximum).
• Maximum Tire Diameter: 35 inches (up to 37 inches with trimming).
• Shock Type: Bilstein 5100 Series Front and Rear Shocks.
• Kit Contents: 2.5-inch lift front coil springs, Sway bar spacers, Brake line extensions, Front track bar relocation bracket, and 4 Bilstein shocks.
