2017-2022 Superduty 4x4 Diesel 4.5"/5.5" Pintop System (CS-F45-PT25-17)

Carli Suspension

Price Beat Guarantee

We'll beat any competitor by $5. Guaranteed.

$7,669.44 CAD
Special Order - Average 2-4 Weeks for Fulfillment

Build Your Kit

One of the best off-road suspension systems Carli offers, the Pintop 4.5" lift kit provides you with an all-around terrific ride over any terrain. No compromises were made with the development of this kit. Featuring Carli-specific, blueprinted, King 2.5” shocks that provide 55% more piston surface area and are the pinnacle of performance and capability. These pintop 2.5 remote reservoir shocks provide more fluid volume and piston movement, which results in improved heat dissipation, consistent damping, and a smoother, more comfortable ride. Fully rebuildable, serviceable, and tuneable for whatever your preference is.

Sway Bar Options

Required

Rear Leaf Options

Required

Leaf Spring Shackle

Optional

The factory shackle is very strong BUT the design is not conducive to a smooth ride. The Carli shackle is constructed of 1/4″ American cold-rolled steel. The mid-length gusset ensures no deflection while the serviceable bushings offer a far superior ride to the bind of the factory bushings.

Long Travel Bags

Optional

Fabricated Radius Arms

Optional

Steering Stabilizer - High mount

Optional

Bolt in replacement for the factory stabilizer. Adjustable from 70-200 psi to run neutral (no directional influence at 70psi) or at 200psi to counter the right-hand pull inherent to tires like Toyo Mud Terrains.

Low Mount Steering Stabilizer

Optional

Bolt in steering stabilizer which compliments a Carli, or factory, high mount stabilizer. Adjustable from 70-200 psi to run neutral (no directional influence at 70psi) or at 200psi to counter the left-hand pull inherent to tires like Nitto Trail Grapplers.

Carrier Bearing Drop

Optional

Trophy Hitch

Optional

Get your over-sized spare out of your bed - crank it into the factory location and secure it with our 3-way tie-down with the Carli Trophy hitch. Boasting 16,000lbs. of capacity via the 3" hitch receiver, direct bolt in installation, and up to a 38" spare tire in the factory location!

Subtotal

Part Specs
Warranty
Description

One of the best off-road suspension systems Carli offers, the Pintop 4.5" lift kit provides you with an all-around terrific ride over any terrain. No compromises were made with the development of this kit. Featuring Carli-specific, blueprinted, King 2.5" shocks that provide 55% more piston surface area and are the pinnacle of performance and capability. These pintop 2.5 remote reservoir shocks provide more fluid volume and piston movement, which results in improved heat dissipation, consistent damping, and a smoother, more comfortable ride. Fully rebuildable, serviceable, and tuneable for whatever your preference is.

Part Number: CS-F45-PT25-17

Features
  • Front and rear shock package, brake line kit, radius arm drop brackets, bump stop drops, caster correction shims, and an adjustable track bar
  • Increases wheel travel to 11" front and 13" rear
  • Requires but does not include rear leaf spring option and sway bar option
  • Fits up to 37" tires with ease for a more aggressive appearance and better off-road performance
  • More fluid volume and piston movement, which results in improved heat dissipation, consistent damping
  • Fully rebuildable, serviceable, and tuneable for whatever your preference is
Notes
  • A "Base Kit" SKU must be accompanied by the SKU of a Leaf Spring option to form a complete system

Fitment:

  • 5.5" Lift - 2020+ F250/350 4x4 Diesel, Base Kit
  • 4.5" Lift - 2017-19 F250/350 4x4 Diesel, Base Kit

Warranty
Limited 1 (One) Year Warranty
