2019-2022 Sprinter 2500 4x4 Complete Striker 2" Lift Kit, Front and Rear (7057)

Push deeper into the backcountry with the Van Compass complete Striker 2" lift kit for the 4x4 Sprinter. Developed to lift the van with as few compromises as possible, it uses machined and welded spacers to relocate the front subframe so the CVs, tie rods, and control arms all cycle in their factory geometry, while a taller Mini Leaf Spring pack, longer sway bar links, shock relocation brackets, and bump stop spacers keep the rear working cleanly. With the right wheel offset and fender trimming you can run a 35x12.50 tire for a huge gain in traction and ground clearance.

Features

• Front and rear bolt-on system for the 4x4 Sprinter
• Machined and welded spacers relocate the front subframe to preserve factory CV, tie rod, and control arm geometry
• Taller Mini Leaf Spring pack with longer sway bar links, shock relocation brackets, and bump stop spacers in the rear
• Clears up to a 35x12.50 tire with proper offset and fender trimming
• 2" of lift front and rear for added clearance and a more capable stance

Included Components

• Front 2" strut spacers
• Front 2" subframe drop spacers
• Engine and transmission mount 2" lift spacers
• CNC Machined 2" steering shaft extension
• Low pressure power steering hose extension
• Front brake line relocation brackets
• 6-leaf Mini Leaf Spring pack
• Extended rear sway bar links
• Rear lower shock relocation brackets
• Rear bump stop drop brackets
• Wind assist or headlight leveling sensor bracket
• All necessary hardware and detailed instructions

Important Notes

• Fits up to a 35x12.50 tire with proper wheel offset and fender trimming
• Offset Wheels Recommended

Installation Instructions

• 2015-2018 NCV3 4x4 Striker 2" Front Kit Installation Instructions
• 2019-2022 VS30 4x4 Striker 2" Front Kit Installation Instructions
• 2015-2018 NCV3 4x4 Striker 2" Rear Kit Installation Instructions
• 2019+ VS30 4x4 Striker 2" Rear Kit Installation Instructions

Labor Time

Recommended shop labor time: 12 hours.

Specifications

• Grade Type: Regular
• Maximum Lift: 2.0 IN
• Maximum Lift Front: 2 IN
• Maximum Lift Rear: 2 IN
