2019-2024 Ram HD 4.5" Coil Lift Kit Front Rear Track Bar Brackets Coil Springs Falcon Shocks (49-19420)

The ReadyLIFT 4.5-inch Coil Spring Lift Kit for 2019-2024 Ram 2500 Diesel trucks is designed for owners who want a significant increase in height without sacrificing performance. These model-specific linear-rate springs are tuned to handle the high-torque Cummins powertrain, ensuring the front end doesn't sag. The system includes vital geometry correction components, such as a track bar relocation bracket and radius arm drop brackets, to preserve factory steering feel and prevent vibration, making it a reliable choice for running 37-inch off-road tires.

Features

• Provides a 4.5-inch front lift for a commanding off-road stance and extra ground clearance.
• Model-specific linear-rate coil springs are tuned specifically for the weight of the diesel engine.
• Includes heavy-duty radius arm drop brackets to maintain proper caster angles.
• Heavy-duty track bar relocation bracket ensures the front axle remains centered.
• Maintains factory-standard ride quality, suspension travel, and handling characteristics.
• Preserves original towing and hauling capacities for heavy-duty work.
• Simple bolt-on design with no permanent vehicle modifications required.

Notes

• Vehicle alignment and headlamp aim should be adjusted following installation to ensure safety.
• Use of shock extensions or longer aftermarket shocks is required for proper performance.
• Professional installation by a certified mechanic is recommended due to the complexity of the lift.

Compatibility Notes

• Fits 2019–2024 Ram 2500 4WD trucks equipped with the Cummins turbodiesel engine.
• Compatible with both Standard Output (SO) and High Output (HO) diesel models.
• Not compatible with 6.4L HEMI gasoline engines or 2WD models.
• Not compatible with Power Wagon models or trucks with factory front air suspension.

Tire Fitment

• Recommended Maximum Tire Size: 37x12.50.
• Recommended Wheel: 9-inch wide wheel with +12 to +18 offset for a rub-free fitment.

Specs

• Front Lift Height: 4.5 inches.
• Spring Type: Diesel-specific linear-rate coil springs.
• Kit Contents: Two (2) Front Coil Springs, Radius Arm Drop Brackets, Track Bar Relocation Bracket, Sway Bar Drops, and Bump Stop Extensions.
