2019-2024 Ram HD 6" Lift Kit Bilstein Shocks Ring Crossmember High Output Diesel (49-19620)

The ReadyLIFT 6-inch Big Lift Kit for 2019-2024 Ram 3500 High Output Diesel trucks is an all-inclusive solution for owners seeking maximum height and refined performance. Featuring heavy-duty radius arm drop brackets and diesel-specific front coil springs, this system corrects vital suspension geometry for a "better-than-factory" feel. The kit includes a forged dropped pitman arm and a track bar relocation bracket to ensure precise steering and centered axle alignment, providing the necessary clearance for aggressive 37-inch off-road tires.

Features

• Provides a full 6-inch front lift and a leveled rear stance.
• Driveline Indexing System (DIS) re-clocks the transfer case to optimize driveline angles and eliminate vibration.
• Model-specific front coil springs are tuned specifically for the heavy High Output diesel engine.
• Heavy-duty radius arm drop brackets maintain proper caster and steering geometry.
• Forged dropped pitman arm and track bar relocation bracket ensure accurate steering and axle centering.
• Heavy-duty 3/16-inch plate steel front skid plate offers essential underbody and differential protection.
• Includes rear lift blocks and add-a-leaf components to maintain factory load-carrying capacity.
• Retains the factory turning radius and overall towing capabilities.

Notes

• The "Auto 4 Hi" feature is not recommended for use after installation.
• ReadyLIFT recommends professional installation due to the complexity of the driveline indexing and suspension overhaul.
• Vehicle alignment and headlamp aim must be adjusted following installation for safety and performance.

Compatibility Notes

• Fits 2019–2024 Ram 3500 4WD trucks equipped with the High Output (H.O.) Cummins turbodiesel engine.
• Specifically designed for models with the Aisin 6-speed transmission and the larger transfer case output.
• Not compatible with Standard Output (S.O.) diesel or 6.4L HEMI gasoline engines.
• Not compatible with Dually (DRW) models or trucks with factory rear air suspension.

Tire Fitment

• Recommended Maximum Tire Size: 37x12.50.
• Recommended Wheel: 9-inch wide wheel with +12 to +18 offset for a rub-free fitment.
• Stock wheels can be reused with tires up to 12.50 inches wide (minor trimming may be required).

Specs

• Front Lift Height: 6 inches.
• DIS Material: CNC-machined billet aluminum.
• Kit Contents: Front lift springs, DIS indexing ring, radius arm drop brackets, dropped pitman arm, track bar relocation bracket, sway bar drops, bump stop extensions, rear blocks, add-a-leaf, and hardware.
