2020-2022 Superduty 3" Lift Kit with FOX 2.0 Performance Shocks (BDS1549FS)

BDS 3" radius arm lift kit for Ford Super Duty diesel trucks, with clearance for up to 35" tires. Up front are diesel-specific Pro-Ride coil springs, heavy-duty replacement radius arms that correct caster, a 1-3/8" solid steel adjustable track bar to recenter the front axle, sway bar relocation, brake line brackets, and nitrogen charged shocks. The rear uses a fabricated lift block, longer u-bolts, and NX2 Nitro or FOX Performance shocks.

Features

• 100 percent bolt-on installation
• Pro-Ride dual rate coil springs ride smooth through any terrain
• Heavy duty tubular steel radius arms correct caster while maximizing ground clearance
• Adjustable solid steel track bar recenters the front axle
• Fabricated steel blocks provide a level stance front to rear
• Standard NX2 Nitro shocks with vehicle-specific valving
• Upgrade to FOX 2.0 Performance Series shocks for max on- and off-road performance

Specs

• Front Lift Method: Coil Spring
• Rear Lift Method: Block
• Shocks Included: Yes
• Front Lift Height: 3 inch
• Rear Lift Height: 1.5 inch

Notes

• Trimming may be required
• 35x12.5 with 17x9 and 5" backspace
• 35x12.5 with 18x9 and 5" backspace
• 35x12.5 with 20x9 and 5" backspace

Includes

• BDS013108, 2017-2024 F250/F350 1 inchRear Block Kit (UPC 658848613052)
• BDS013261, 2020-2024 F250/350 2.5 inch Front Box Kit (UPC 658848613236)
• BDS033251, 2005-2024 Ford Super Duty 2.5 inch Coil Spring Box Kit, Front Diesel, Pair (UPC 658848616480)
• BDS123251, 2005-2022 Ford F250/F350 Radius Arm Kit, Pair (UPC 711745604087)
• FOX98224710, Fox 2.0 Shock 23.27 x 14.65 x 2- S50/EB1
• FOX98224717, Fox 2.0 Shock 30.05 x 18.45 x 2- EB1/EB1
