2020-2025 Superduty 4WD 2.5" Coil Spring Leveling Kit w/ Falcon Shocks (46-20253)

The ReadyLIFT 2.5-inch Coil Spring Front Lift Kit is a premium leveling suspension system engineered exclusively for Ford Super Duty diesel trucks. This kit provides 2.5 inches of front lift using heavy-duty coil springs and features the high-performance Falcon 1.1 Monotube Series shocks on all four corners. This bolt-on system is designed to deliver a rugged, leveled stance and a smooth, controlled ride, making it a performance and ride-enhancing alternative to standard leveling spacers.

Features

• Provides 2.5 inches of front leveling lift via heavy-duty coil springs.
• Includes four Falcon 1.1 Monotube Shocks (front and rear).
• Features a front track bar relocation bracket.
• Includes model-specific brake line extension brackets, bump stop extension brackets, and front sway bar frame mount extension brackets.
• Bolt-on system that requires no structural modifications.
• The shocks are precision-tuned for increased stability, improved ride quality, and a consistent controlled feel on and off-road.

Notes

• 2023-2025 Tremor models will gain approximately 1.125 inches over stock ride height.
• For trucks with the Onboard Scale option, the Auto-Leveling Headlight Bracket Kit (PN: 67-23210) is required.
• Some 2020-2025 Super Duty trucks may need to retain the factory track bar bracket if the front axle is shifted off center with the provided bracket.
• Not recommended for TREMOR editions.

Compatibility Notes

• Engineered exclusively for Ford Super Duty diesel trucks.
• Not recommended for 2WD or gas trucks because the springs are designed and rated for the heavier diesel engine, and installation on a gas truck will result in a nose-high stance and a stiff ride.
• Also compatible with F450 models, though you may get less lift due to heavier spring ratings.

Tire Fitment

• Allows for up to 35-inch tall tires for no rub.
• With minor trimming, fitment is possible for up to 37-inch tall tires.
• Ideal tire/wheel combo is 35x12.50 on a 9 or 10-inch wide wheel with +25 to 0 offset for no rub.

Specs

• Front Lift: 2.5 inches (maximum).
• Maximum Tire Diameter: 37 inches (with trimming).
• Shock Type: Falcon 1.1 Monotube Front and Rear Shocks.
• Kit Contents: 2.5-inch lift front coil springs, Sway bar spacers, Brake line extensions, Front track bar relocation bracket, and 4 Falcon 1.1 Monotube shocks.
