2023-2026 Sprinter 2500 AWD Suspension Lift Kit (7219-OPTI)

Van Compass

Price Beat Guarantee

We'll beat any competitor by $5. Guaranteed.

$5,661.72 CAD
Special Order - Average 2-4 Weeks for Fulfillment
Part Specs
Warranty

The Van Compass Striker AWD lift kit creates the clearance needed to fit larger tires and push deeper into the backcountry with confidence, engineered specifically for the Sprinter AWD platform. Developed over years of design, it lifts the van with as few compromises to the factory geometry as possible, keeping the CVs, tie rods and control arms cycling in their original Mercedes-specified range. With proper wheel offset and fender trimming, it opens the door to a 35x12.50 tire for a big gain in traction and ground clearance.

Features
  • Engineered specifically for the Sprinter AWD platform
  • Machined and welded front subframe spacers preserve factory CV, tie rod and control arm geometry
  • Opti-Rate rear leaf spring pack lets you fine-tune spring rate and ride height for your build
  • 2" rear lift block, longer sway bar links, shock relocation brackets and bump stop spacers keep everything cycling without bind
  • Best suited to heavy vans in the 9,000-10,000 lb range and up, including upgraded Storytellers, Revels and 170 EXT builds
Included Components
  • Front 2" strut spacers
  • Front 2" subframe drop spacers
  • Engine and transmission mount 2" lift spacers
  • Front differential cam bolt kit
  • CNC Machined 2" steering shaft extension
  • Low pressure power steering hose extension
  • Front brake line relocation brackets
  • Opti-Rate Rear leaf spring pack
  • 2" rear lift block
  • Extended rear sway bar links
  • Rear lower shock relocation brackets
  • Rear bump stop drop brackets
  • Wind assist or headlight leveling sensor bracket
  • All necessary hardware and detailed instructions
Important Notes
  • Up to 35x12.50 Tire with fender trimming
  • Raises Front 2"
  • Raises Rear 2"
  • +38 mm Offset Wheels Recommended
  • With this lift kit, tires up to 35" diameter and 12.5" width can fit. Trimming of the fender liner and mud flap is required.
Installation Instructions
Labor Time

Recommended shop labor time: 12 hours.

Specifications
  • Maximum Lift: 2.0 IN

Warranty
60 Days-Finish; Limited Lifetime-Structural

Vehicle Fitment

Part Specifications

  • Part No.
    7219-OPTI
  • Cross Reference #
    810185262717
  • Vendor
    Van Compass
  • Shipping Weight
    310.0 lb
  • Length
    24 in
  • Width
    42 in
  • Height
    54 in
  • Prop 65
    ⚠️ Warning: Cancer & Reproductive Harm
  • Compatibility Notes
    Up to 35x12.50 Tire with fender trimming; Raises Front 2"; Raises Rear 2"; +38 mm Offset Wheels Recommended; With this lift kit, tires up to 35" diameter and 12.5" width can fit. Trimming of the fender liner and mud flap is required.
