2023-2026 Sprinter 3500XD AWD Suspension Lift Kit (7224-OPTI)
Van Compass
Price Beat Guarantee
We'll beat any competitor by $5. Guaranteed.
Price Match Request
2023-2026 Sprinter 3500XD AWD Suspension Lift Kit (7224-OPTI)
Regular price
$5,840.14 CAD
Unit price
Special Order - Average 2-4 Weeks for Fulfillment
The Van Compass Striker AWD Sprinter 3500 2" lift kit creates clearance for larger tires and adds ground clearance under the van, helping you avoid obstacles on the trail to your remote campsite. It retains the stock suspension geometry while improving on factory ride quality and payload rating with a full replacement leaf spring pack matched to your vehicle's weight.
Features
- 2" of lift for larger tires and added ground clearance
- Full replacement rear leaf spring pack specified for your vehicle's weight
- Improves on factory ride quality and payload rating
- Retains stock suspension geometry
- Components built in the USA, powder coated for durability and corrosion resistance
Included Components
- Front 2" strut spacers
- Front 2" subframe drop spacers
- Engine and transmission mount 2" lift spacers
- Front differential re-clocking cams
- CNC Machined 2" steering shaft extension
- Low pressure power steering hose extension
- Front brake line relocation brackets
- Opti-Rate replacement rear leaf spring pack
- Rear sway bar drop brackets
- Rear lower shock relocation brackets
- Rear bump stop drop brackets
- Wind assist or headlight leveling sensor bracket
- Rear wind assist extension bracket - 1/8" hot rolled steel
- All necessary hardware
Installation Instructions
- 2023+ VS30 AWD Striker 2" Front Kit Installation Instructions
- 2015+ Sprinter 3500 AWD and 4WD Rear Lift Kit Installation Instructions
- Sprinter 3500 4WD Rear Spring Installation Instructions
Labor Time
Recommended shop labor time: 12 hours.
Specifications
- Grade Type: Performance
- Maximum Lift: 2.0 IN
Warranty
Warranty
60 Days-Finish; Limited Lifetime-Structural
Vehicle Fitment
Vehicle Fitment
Part Specifications
-
Part No.7224-OPTI
-
Cross Reference #810185262731
-
VendorVan Compass
-
Shipping Weight312.0 lb
-
Length
-
Width
-
Height
-
Prop 65⚠️ Warning: Cancer & Reproductive Harm
