Universal Elite Series Type B Yellow Fog Lamps (DIODD5137P)

If you are ready to upgrade your factory lighting to a professional-grade standard, the Elite Series Type B Fog Lamps in Selective Yellow are the ultimate choice for your vehicle. Specifically designed for many Toyota, Lexus, and Subaru applications, these lamps are a ground-up performance redesign, not just another LED bulb replacement. They feature a custom-engineered, patent-pending toroidal lens that produces an industry-leading 80-degree spread of intense light, wider than any other aftermarket fog lamp available. The 3000K yellow output is specifically optimized for high contrast and reduced glare in heavy fog, rain, or snow. Beyond the main beam, each lamp includes an integrated amber backlight that illuminates the entire lens, providing a distinctive look that matches your vehicle's other accent lighting.

Features

• Superior Light Spread: Custom toroidal optics deliver a massive 80-degree spread of light, providing excellent peripheral vision and a sharp, premium color flicker at the cutoff.
• Selective Yellow Performance: The 3000K color temperature is engineered to cut through airborne particles like dust and fog while providing high contrast for safer nighttime driving.
• Integrated Amber Backlight: Features a secondary amber glow that fully illuminates the main lens, serving as a premium styling accent even when the main beam is off.
• Plug-and-Play Installation: Designed for a direct bolt-on fit in factory mounting locations, including all necessary H11 wire adapters to connect directly to your OEM bulb sockets.
• American-Assembled Quality: 100% assembled in St. Louis, Missouri, using UV-coated lenses and precision aluminum castings for maximum durability and weather resistance.

Specs

• Traffic Pattern : SAE F3 Foglamp (80° Spread)
• Color Temperature : 3000K (Selective Yellow)
• Measured Output : 1,650 Lumens (Main Beam)
• Peak Beam Intensity : 8,700 Candela
• Wattage : 15W (Main Beam), 0.3W (Backlight)
• Current Draw : 1.2A @ 13.2V
• Operating Voltage : 9-16V
• Materials : Copper PCB, UV-Coated Polycarbonate Lens, Precision Aluminum Casting
• Weather Rating : IP68 Waterproof

Includes

• Fog Lamps : Two (2) Elite Series Type B Fog Lamps
• Adapters : Two (2) H11 DT backlight tap wires and T-taps
• Guide : One (1) Installation and Mounting Guide

Notes

• Compatible with a wide range of Toyota, Lexus, and Subaru vehicles requiring Type B mounting
• Backlight automatically deactivates when the main beam is turned on
• Backed by an industry-leading 8-year limited warranty
