Universal S8 Series Driving Combo Pattern 40" LED Light Bar (BAJ704003)

The S8 Straight 40-inch LED Light Bar in the Clear Driving/Combo configuration is a high-output, versatile lighting system designed to provide total trail coverage for high-speed off-road applications. This expansive 240W unit utilizes a hybrid optic system that integrates 42-degree horizontal driving reflectors for wide-angle peripheral saturation and 9-degree spot reflectors for a concentrated distance punch, delivering a total of 25,400 lumens. The optically clear hard-coated polycarbonate lens ensures maximum transmission of the 5000K daylight color temperature, which enhances terrain definition and significantly reduces driver eye fatigue. Engineered with uService technology, the unit allows for field-serviceable lens and O-ring replacement, while the CopperDrive thermal management system and scalloped housing ensure the LEDs maintain peak performance through efficient heat dissipation.

Features

• Driving/Combo beam pattern provides a seamless transition between wide-angle cornering and focused distance illumination.
• Integrated amber backlight delivers a secondary low-power accent mode for enhanced vehicle aesthetics and visibility.
• uService integration enables rapid, user-level lens servicing and pattern customization in the field.
• CopperDrive thermal management manages heat dissipation to ensure stable performance at a 16.0A draw.
• Hard-coated polycarbonate lens provides IK10-rated impact resistance against high-velocity trail debris.
• MoistureBlock technology utilizes a specialized cord grip to prevent water and dust from wicking into the housing.

Notes

• Includes a 40-inch S8 Straight LED light bar and heavy-duty mounting hardware.
• Optimized for Lighting Zones 1, 2, and 3, providing comprehensive coverage from the foreground to the mid-field.
• A high-current S8 wiring harness is required to independently operate the main light bar and the secondary amber backlight.
• Exceeds MIL-STD810G standards for durability against vibration, shock, and extreme environmental conditions.
