2011-2026 Superduty 6.7L Premium High-Efficiency Engine Oil Filter (314000767)

Description

This oversize PPE Engine Oil Filter has over 20 percent more specially engineered filter media equaling 552 square inches. A perforated metal center core provides sufficient support, preventing collapse.

Blow-by is eliminated by an integrated coil spring. This filter also includes a high-power magnet to catch ferrous particles, preventing them from causing internal damage. The silicone anti-drain-back valve prevents the engine dry starts.

The bypass valve features a stiffer spring and a rubber seal that maximizes protection.

The OEM filter has only 455 square inches of 20-micron filtration capability. The leaf spring in the factory filter loses tension over time and can lead to dirty oil blow-by.

(Replaces Motorcraft FL-2051S)

Features

• MicroPure XR® filtration with a 5-micron nominal rating
• 552 Square inches of ultra-fine synthetic microfiber media, a 21% increase over the stock filter
• Integrated high-temperature rated neodymium magnet captures ferrous particles, providing extra engine protection
• Built-in bypass valve with precision coil spring and steel-NBR poppet
• High-strength steel base plate with increased thread engagement and large oil passages
• Durable metal center tube provides excellent media support and pressure resistance
• TorqSTOP™ Technology prevents over-tightening and reinforces the gasket against high oil pressures
• Silicone anti-drainback valve delivers superior protection during engine start-ups
• Heavy-duty coil spring ensures a secure seal and prevents oil blow-by, maximizing filtration performance
• Pleat-locking spiral bead keeps media pleats evenly spaced for consistent filtration performance
